The K9 Roof Rack System from Eezi-Awn is a revolutionary advancement in expedition-style racks; it is thinner, lighter, stronger, quieter, more functional, more aerodynamic, more durable, and more aesthetically complimentary to your vehicle than the competition.
Capacity of the K9 roof rack system is broken into two measurements, static weight and dynamic weight. Static is when the vehicle is stationary. Dynamic is when the vehicle is in motion. We have not tested the K9 racks on vehicles to the point of roof failure. We can tell you what we have tested ourselves effectively. A dynamic capacity in the range of 500 pounds is possible. A static capacity of 1000 pounds is possible. An example of static load increase would be adding people in the tent on the roof. Please understand these capacities are on vehicles that have modified suspensions designed to manage this amount of weight. They are not a warrantied or guaranteed capacity. Your load capacity will vary.
Installation of this rack system can be done by one person in approximately 1-1/2 hours. Help lifting the platform on the roof would be appreciated. You start by removing the factory roof rack, then attach the K9 mounting rail to the roof, followed by a full set of feet, and finally a platform on top. Please see our Roof Rack Installation 101 video for more in depth explanation. Written instructions are also provided with each rack system. Click Here to Download Instructions.
The 700mm long rack has a shorter mounting rail that attaches to the front (2) mounting points, and the center mounting point. It comes with (4) feet, (2) 40mm rear feet and (2) 50mm front feet. The 1M and the 1.4M racks use the full length mounting rail, mounting at (2) front points, (1) middle, and (2) rear. The 1M platform comes with (4) feet, (2) 40mm rear feet and (2) 50mm front feet The 1.4M rack comes with (6) feet, (4) 40mm rear feet, (1) 40mm middle feet, and (2) 50mm front feet.
The Eezi-Awn K9 Roof Rack System comes with a complete array of bolt on accessories. Jerry Can holders, Axe mounts, Shovel mounts, Hi-Lift Mounts, Max Trax Mounts, Awning Mounts, Under Rack Table mounts, and much more. Take a look at the accessories page to see all our options.Thule & Yakima Compatible
The K9 Roof Rack is also the only overlanding rack on the market that is easily compatible with your existing Thule or Yakima sports bar mounts for bikes, kayaks, etc. With store-accessible 6mm hardware that attaches to the K9's perimeter, your hobbies won't become obsolete with your "old gear."
Thule Models Podium Foot Pack 460 Fit Kit KIT3101 Yakima Models (1) Skyline Tower (2) Landing Pad 4
"The K9 Roof Rack System is a welcome alternative to the cage-style racks that once defined the typical overland roof rack. It is sleek, understated, and complimentary to the aesthetics of vehicles new and old. It is most importantly, remarkably robust, an attribute we would naturally expect from the engineers at Eezi-Awn."
-- Christophe Noel, Executive Editor, Expedition Portal (Read The Full Review)SHIPPINGDue to the size and weight of this item, we will only ship within the contiguous U.S. using truck freight.COMMERCIAL FREIGHTPlease note that free shipping only applies to delivery at a commercial address. Additional fees may apply to Alaska and Hawaii.RESIDENTIAL FREIGHTUnfortunately certain items are ineligible for residential delivery. If you plan to ship to a residential address and the product is authorized to ship to a residential address, you will be charged an additional fee which is not automatically applied at checkout. Please write "Residential" in the notes section and we will contact you with a quote. If you do not make this denotation, you are responsible for all related fees and potentially the original shipping charge.
K9 Roof Rack Features
- Fully Welded 1-3/8"H Low-Profile Platform
- Light Weight All Aluminum Construction
- All Components Are Anodized And Powder Coated Matte Black
- 5-1/8" Wide M8 T-Slot Slats, Running Front to Back
- Semi-Elliptical Bottom Cross Braces To Reduce Wind Noise
- M6 T-Slot Around Top Perimeter With Rounded Top Edge
- 5 Lengths and 3 Widths Of Platform Available
- Multiple Mounting Configurations Including Gutterless/Gutter/OEM Rack Mounts
- Full Compliment of K9 Roof Rack Accessories For Top/Bottom/Side Mount
- Infinite Gear Organization Configurations
- Includes All Installation Components & Hardware
Feet vs LegsThe K9 Roof Rack Kit comes with various components. The Mounting Rail is compatible with Gutter-Less Roofs, like those found on the Toyota 4Runner, Tacomas, or 100 / 200 Series Land Cruisers. K9 Roof Rack Feet are then attached to that Mounting Rail. When there is a vehicle with a Gutter, we use K9 Roof Rack Legs.
The K9 Roof Rack Feet come in 3 basic sizes: 40mm / 2.5", 65mm / 3.25", and 90mm / 4". Each of these feet do have a height adjustment range, measuring from the top of the mounting rail vertically to the top of the foot where the platform attaches. At first glance, the available sizes are in the middle of their ranges; this is because Eezi-Awn uses their middle measurement height as the identifier.
40mm (2.5") height range 55-65mm (2.25" - 2.5")65mm (3.25") height range 75-90mm (3" - 3.5")90mm (4") height range 95-115mm (3.75" - 4.5")
The K9 Roof Rack Legs are all measured from the bottom of the leg that sits in the gutter, vertically to the top of the leg where the platform attaches. Each size has 15mm, or a little over 0.5" of height range upward from the listed height.
150mm (6") height range 150-165mm (6" - 6.5")210mm (8.25") height range 210-225mm (8.25" - 8.75")250mm (9.75") height range 250-265mm (9.75" - 10.25")300mm (11.75") height range 300-315mm (11.75" - 12.25")
We offer Free Shipping in the contiguous United States on all brands we import.
- National Luna
- Escape Gear
Orders to Alaska and Hawaii may require additional charges.
Eezi-Awn products will be shipped free of charge.
Due to the size and weight of the roof top tents and rack platforms, we will only ship within the contiguous U.S. using truck freight. We will ship to any commercial address with a fork lift or a loading dock, or a freight facility close to you for pickup. This can be unloaded on a dock with a pallet jack. Smaller items that can be shipped by ground can be delivered to residential or commercial addresses.
National Luna products will be shipped free of charge.
Due to the size and weight of the larger fridges (size 110L and larger), we will only ship within the contiguous U.S. using truck freight. We will ship to any commercial address with a fork lift or a loading dock, or a freight facility close to you for pick up. This can be unloaded on a dock with a pallet jack.
AluBox cases size 10L to 175L will be shipped to a residential or commercial address free of charge.
Due to the size and weight of the larger boxes (size 192L and larger), we will only ship within the contiguous U.S. using truck freight. We will ship to any commercial address with a fork lift or a loading dock, or a freight facility close to you for pick up. This can be unloaded on a dock with a pallet jack.
Escape Gear products will be shipped to a residential or commercial address free of charge. We carry a great deal of Escape Gear inventory, and will fulfill all orders that we have from our US facility. In some cases, Escape Gear products are custom-made and built one at a time in Cape Town, South Africa. This means that they ship directly from Cape Town to you. Our best estimate for delivery of these single-batch products is 6-8 weeks. You will be notified of this production and delivery time frame at the time of order.
Please note that there is a 4-6 week production lead time on all Trail Kitchen products. Trail Kitchen Van Kitchen and Mini Van Kitchen products are shipped by truck freight from the manufacturer. This pricing can vary between $150 to $500 per package based on distance and destination. You will checkout with a zero cost shipping payment and we will contact you with an exact quote and collect payment at that time. All other products ship at a flat rate of $55 at checkout.
Return, Exchange, and Cancellation Policies
- If your order contains incorrect products or has been damaged in transit, documentation and photos are required within 72 hours of receiving the order.
- If you are dissatisfied with the product once your order is received, you are solely responsible for return shipping costs.
- Products must be returned in original packaging and adequately protected for carrier handling. Returned product will be inspected for damage or evidence that it was installed. Upon return, Goose Gear, in its sole discretion, will assess product’s condition for resale. A restocking fee of 20% will be applied to the amount. If product is not resalable, we cannot accept a return.
- Once an order is placed, if that order is canceled within its predicted production timetable, you will be charged a 20% cancellation fee.
- Original Purchaser is eligible for warranty coverage with valid proof of purchase.
- All warranty issues will be resolved directly by Goose Gear and End User, where it applies. Goose Gear will communicate directly with End User to review defect and extend appropriate remedies as warranted.
NO MORE, NO LESS
The products we carry vary in size and weight as much as your delivery location. In light of this fact, we will charge you only what it costs us to ship to you, no more and no less. Unless otherwise requested, we will select a shipping option that minimizes cost. We will inform you of the cost of shipping as reasonably soon as possible. We will be happy to ship via Next Day Air, Second Day Air, or Three Day Select if you request it and are willing to pay for it.
You spent money on it and we want to ensure its safe delivery. All shipments under $200 will not require a signature for delivery. All shipments over $200 will require a signature unless otherwise specified. Please contact us if you would like to remove this feature from your order. This service is complimentary.
Please be aware that larger items, including Eezi-Awn tents and racks and Goose Gear storage solutions, which are too large for traditional ground shipping, will require truck freight for delivery, and custom items shipping internationally are not eligible. We offer Free Domestic Shipping on Eezi-Awn tents and racks to a commercial address. Roof Top Tents will require a loading dock or forklift or a freight terminal close by for pick up. Roof Racks will require the ability to receive a large platform box; however Rack Feet and Rack Rail can be shipped to your residence. If you order a tent or rack from our website, contact us by phone or email and we will work with you to secure the most economical delivery of your product we can.
If you plan to ship a large item noted above to a residential address, please check that option during checkout, and you will be charged a small additional fee. Because of their size, Hard Shell Roof Top Tents cannot be delivered to a residence.
CANADA & INTERNATIONAL SHIPPING
Equipt is the North American distributor for Eezi-Awn, National Luna, Alubox and Escape Gear. We have contractual agreements with our vendors to not ship products outside North America. An option for you would be to ship our products to a freight forwarder within the US, where you can arrange to continue their journey to your shores.
We do offer shipping to Canada. Shipping expenses will apply on all lines. Contact us directly for costs to ship to your Canadian address. We will not be responsible for any duties or fees associated with crossing the Canadian border to your residence. We ship a lot of products to independent packaging stores all along the US/Canadian border, for Canadian customers to pick up on our side. This option is very cost effective, if you have the opportunity to come to the US.
TURN AROUND TIME
We always work to ship every order as quickly as possible, but we're a small team and we ask that you read our shipping policy so that we can set the right expectations.
Unless an expedited shipping method is requested, it's best to assume that from the time we receive your order during our office hours, Monday through Friday, and add it to our queue, it takes our team a few business days to start preparing your shipment. There is also the additional shipping time based on your location from our warehouse in Salt Lake City, Utah. These transit maps offer a helpful timeline for most orders:
Please note that we do not handle or ship orders over the weekend.
Shipping around the holidays can get a little crazy. We do our best to get your packages out within 48 hours, but once they leave our warehouse, it's in the hands of our carriers to handle the rest. Oftentimes they experience delays and unforeseen weather. The best way to ensure your package arrives by a certain date is to expedite the shipping, not wait until the last minute, and even order a few extra days in advance.
If your order did not arrive accurately, we will pay the return shipping charges and refund to you the amount of shipping you paid on that particular product. If you received what you ordered but are dissatisfied with it, you will be responsible to pay the return shipping charges and the initial shipping charge.
Please note that order cancellations on Goose Gear products are subject to a 20% restocking fee.
